XH SERIES HIGH-VOLTAGE
LITHIUM BATTERY FORKLIFT

Lithium-powered forklifts built for high performance and heavy-duty reliability with capacity of 20,000 to 25,000kg

Overview

XH series high-voltage counterweight lithium battery forklifts are an innovative range independently developed by Hangcha. Utilizing the new energy vehicle voltage platform for the first time, these forklifts build on decades of expertise in electric and internal combustion forklift technology while breaking away from traditional design concepts.

Kilogram icon

20,000 – 25,000 KG

Load Capacity

Height Icon

0 – 7000 mm

Lift Height

Battery Icon

Li-Ion

Dirve Types

Product Features

The wide-opened hood better facilitate repair and maintenance of electrical components.

The over-turnable cab and electric tipping cylinder make tipping easier and more labor-saving.

The vehicle’s high-voltage platform, standard 540.96V or optional 608.58V, equipped with a heavy truck water-cooled standard box features better heat dissipation, longer endurance mileage and more durable battery.

Cab

Fully enclosed integral cab The cab adopts connection with four-point shock-absorbing rubber to reduce vibration, and is equipped with electric and manual tipping mechanisms to facilitate routine maintenance. The large cab floor and ample overhead and leg space enable the driver to enter and leave the cab easily at any time. The fully enclosed cab is heatproof, dust-proof and waterproof.

The wide-view mast with optimized design is unlikely to obstruct the operator’s line of sight. The enlarged opening size of the fork carriage enables a wider view, a large operation space, and excellent ergonomic design.

Excellent heat dissipation Performance

For the first time, a water cooling system is used for controlling the motor, electric control and battery and achieving a good heat dissipation effect, so that the forklift can absolutely carry out long-time and high-intensity operations as internal combustion forklifts.

The vehicle adopts a whole machine controller to redeploy the traction integrated controller (PDU+ DC/DC+MCU) to form an intelligent driving system, being light-weighted, efficient and independent.

Product Gallery
